Pulsar Merger LRF XP35
Pulsar Merger LRF XP35
Couldn't load pickup availability
The Pulsar Merger LRF XP35 is the most compact model in the Merger range, yet it delivers the widest field of view in its class — an impressive 17.8°, making it ideal for fast, intuitive scanning across broad landscapes.
Fitted with a highly sensitive Lynred 640×480 / 17 µm thermal sensor, the XP35 provides outstanding image clarity and contrast, even in poor weather conditions such as mist, rain, or dense vegetation. Its excellent thermal penetration makes it a reliable tool for demanding environments.
With a built-in 1000m laser rangefinder, and a rugged, ergonomic design, the XP35 excels in close to medium-range observation. It’s the perfect choice for bush stalking, night walking, marine safety, pest control, and general thermal imaging use, where wide vision and dependable performance are essential.
Sensor
- Lynred PICO640 a-Si µbolo UFPA
- 640x480 / 17µ / 50Hz
- System NETD <18mK
- Proven reliability MIL-STD 810 : MIL-STD 883 : TWS Qualified
Optics
- F35mm - f1.0 precision germanium lens
- 2x – 16x magnification
- Field-of-view 17.8˚ / 31.3 @ 100m
- Spatial Resolution (IFOV) 1.66’ MOA / 47.9mm @ 100m
- Detection Range 1350m*
General
- Made in Europe by Pulsar
- Powerful 1000m laser rangefinder
- Weight 830 grams with battery
- Size 165x133x68mm
*Based on the standard Johnson's criteria for an object 1.8m x 0.5m
